ART 912-AX is a top-notch solution for any audio application, featuring 48V microphone preamps and line inputs, an internal 6-channel digital mixer with advanced DSP, Bluetooth® stereo audio input, with dual speaker pairing option.

The combination of a 1.75" compression driver, 12" woofer, and two-channel 2100W amplifier, produces 100° x 60° constant directivity coverage for the listening area with up to 130 dB SPL, distortion-free sound.

The sleek cabinet uses a special polypropylene composite material with an M-brace internal reinforcement, making it easy to carry and secure to install on a pole, flown-, wall-, or truss-mounted using the multiple rigging points available.

Built-in 6-channel Digital Mixer
Advanced User Interface w/ touch panel and remote control
1.75" Compression Driver and 12" Woofer
Up to 130 dB Sound Pressure Level
2100W Class-D Bi-Amplification
Dual combo preamp with 48V Power and Mini-jack stereo line input
Bluetooth® stereo audio input, with dual speaker pairing option
True Resistive Waveguide, FiRPHASE, and Bass Motion Control

Frequency Response: 50 Hz ÷ 20000 Hz
Max SPL @ 1m: 130 dB
Horizontal coverage angle: 100°
Vertical coverage angle: 60°
Compression Driver: 1 x 1.0'', 1.75'' v.c
Woofer: 1 x 12'', 2.5'' v.c
Input signal: bal/unbal
Input connectors: Combo XLR/Jack
Output connectors: XLR
Crossover Frequencies: 1600Hz
Protections: Thermal, RMS
Limiter: Soft Limiter
Controls: Color touch panel, data entry/volume encoder, dedicated App for iOS and Android.
Total Power: 2100 W Peak
High frequencies: 700 W Peak
Low frequencies: 1400 W Peak
Cooling: Convection
Connections: VDE
Frequency Response: 20 Hz ÷ 20 Hz
THD+N, 20dB gain, 0dBu out: 0.005% A-Weighted
Processing Channels: 6
Signal Processing: 24 Bit
A/D-D/A conversion: 32 Bit @ 48.0 kHz
Dynamic range: 110
Mic: 2
Remote Controlled Storable Gain: Yes
Gain Range: 0 dB ÷ 42 dB
Input Noise Level: -114 dBu A-Weighted
Mic Inputs Impedance: 6 kohm
Low Cut: 20 Hz ÷ 400 Hz
Phantom Power +48V: Yes
Mono Line: 2
Gain Selection: 0 dB ÷ 22 dB
Line Input Impedance: 21 kohm
A/D Dynamic range: 114 dB
Stereo Line: 1
Gain Selection: 0 dB ÷ 10 dB
Stereo Line Input Impedance (kOhm): 13 kohm
Main MIX: 1
Main Out Impedance: 150 ohm
Main Out Level: 22 dBu
D/A Dynamic Range: 114 dB
RCF Compressors: Compressors on MIC/LINE CH1 & CH2 Inputs
Input Channels EQ: 2 Shelving 1
Description: 3 Band EQ: High and Low band shelving, MID band peak on IN
5 Band EQ: 4 Full Parametric, 1 High Shelving and HPF 24 dB/Oct on amplifier and MAIN output.
Send Effects: 1
Main OUT type: MIX OUT, CROSSOVER OUT with RCF SUBWOOFERS presets, STEREO OUTPUT, CH1 LINK OUT.
Safety agency: CE compliant
Cabinet/Case Material: PP Composite
Hardware: 1 x M10 Top, 1 x M10 each side
Handles: 1 Top, 1 each side
Pole mount/Cap: 35 mm insert
Grille: Steel
Colour: Black
Height: 642 mm / 25.28 inches
Width: 370 mm / 14.57 inches
Depth: 363 mm / 14.29 inches
Weight: 18.7 kg / 41.23 lbs

1 Year Warranty
