FBT PM2000 System ProMaxX 110A & Subline 112SA Active PA Package

The PM2000 System comes complete with the ProMaxX 110A 700W RMS + 200W RMS 131 dB SPL processed active speakers complete with B&C's renowned compression driver technology, PROMAXX combines true made-in-Italy quality and style. At its heart is a purpose-built FBT amplifier module with a switch-mode power supply. For the low frequency section, 700W RMS is driven via a highly efficient Class-D topology, boasting extremely low THD. For HF, meanwhile, 200W RMS is delivered by a Class-H / AB design chosen to ensure the highest definition of audio performance at high frequencies.

Also onboard is a powerful digital signal processing (DSP) platform made available to users of all levels thanks to an intuitive graphical user interface. Located on the rear of the enclosure, the menu-driven system is navigated via a single rotary control with push-to-select functionality.

Users can choose between 6 equalizer presets, each carefully designed by FBT engineers to ensure that every application is catered for (see below). Additionally, 2 preset slots are available for users to form their own designs, using 5 parametric equalizers per slot. Also available is a high-pass filter, a mic/line selector, low, mid and high tone settings and an optional delay of between 0 and 3.5 metres. Finally, users can exclusively choose between two limiter modes, MAX-SPL or MAX-QUALITY, to best suit their performance.

The PM2000 System also comes with the 112SA 700W RMS 130/133 dB SPL processed active subwoofers which are built in birch plywood and aimed to extend the low frequency response to a wide range of FBT speaker systems.

Created with the aim to maximize SPL/SIZE ratio, they have Class D amplifiers, switch mode power supply and Digital Signal Processor with presets to match any other FBT speaker.

With IN/OUT stereo connectors, it is possible to use only one subwoofer with Left and Right speakers

Optional wheels, ergonomic integrated carrying handles and tour-grade plywood cabinets allow an easy transport.

Also included in this package are a pair of connecting poles and all connecting cables.

PROMAXX 110A KEY FEATURES

2-way, bi-amplified, bass reflex design cabinet

Biamped: 700W RMS LF, 200W RMS HF, power amplifiers in Class D for LF and in Class H/AB for HF with switch mode power supplies

Digital signal processor with graphic display

Control Panel features balanced XLR/Jack input, XLR LINK OUT, 2 x Volume, RCA Stereo input, DSP display with rotative encoder and push

2 x M10 suspension points, 35 mm (1,3/8'') top-hat speaker stand socket, wall bracket mount flange plate

90°H x 60°V constant directivity horn

Front of House or Stage Floor Monitor: with 12, 40 and 55 Degree monitoring angles

SUBLINE 112SA KEY FEATURES:

Bass-reflex design with high SPL and punch

320mm (12'') high excursion magnet woofer with 75mm (3'') voice coil

Frequency response from 40Hz to 140Hz

New amplifier engineered and manufactured by FBT, 700W RMS LF in Class D

Digital Signal processor with 8 presets, 2 equalization with 2 LPF Crossover settings, cardioid configuration

Control panel with Stereo XLR in/outs, Volume, EQ presets, 8 steps Delay from 0.25m to 3.5m, Phase Reversal Switch 0-180 degrees, 3 status LED indicators

15 mm (0.59'') birch plywood scratch resistant enclosure with internal bracing

M20 (20mm) top mount speaker stand socket and two aluminum ergonomic FBT handles
