FBT JMaxX 114A 900W Active Speaker
JMaxX 114A Processed 2-way active loudspeaker 700W + 200W – 132 dB SPL (peak)
The FBT JMaxX 114A combines ease of use and versatility for many portable or installed sound applications: musicians, DJs, AVL contractors, rental sound reinforcement, corporate events, houses of worship, bars and clubs.
With its eye-catching gas-injected forms designed to virtually eliminate undesired enclosure resonance and reinforce strong low frequency performance, the 14-inch JMaxX 114A is equipped with FBT’s latest 90° x 60° HF horn design which delivers improved projection, accuracy, and dispersion of the mid and high frequencies.
Providing a myriad of possibilities for bands, DJs and solo artists, as well as for permanent installations, the JMaxX 114A is actually four loudspeakers in one. Derived from a decade of experience of portable sound reinforcement, the carefully tailored equalisation presets offer highly intelligible response for vocals and floor monitoring; slightly boosted response in lounge bar applications; punchy and forward sound for DJs and night venues; and a general-purpose EQ setting that mirrors the original and familiar FBTMaxX voicing.
The JMaxX 114 A features FBT’s latest generation lightweight 700W + 200W Class D power amplifier with universal switch mode power supply, delivering abundant power and headroom to reproduce even the largest transients without distortion.
And a unique 14 Inch Low frequency driver. The 14" Driver fits inside a cabinet the size of a 12" Cabinet yet performs as good as a conventional 15".
This unique speaker.
The result is an amazingly compact speaker with all the power and clarity of a much larger speaker and weighing Just 14Kg this Speaker is a dream to transport.
XLR inputs and outputs, volume control, the EQ presets and filters, and ground lift switch are all conveniently located on a clearly laid out rear panel, making loudspeaker setup and operation intuitive and consistently repeatable.
The JMaxX versatility is further underscored by the many mounting and fixing options that the ergonomically styled cabinets provide. Mounting in fixed installations is made easy using the M10 suspension points or wall bracket flange plates, while portable use is facilitated by the built-in 35mm pole mount socket.
There’s no need for separate stage monitors, as JMaxX’s cabinet profiles are designed with 14°, 40°, and 55° wedge angles, and when used with the specific floor monitoring EQ presets, will ensure that performers hear themselves with ultimate clarity.
Weighing just 14Kg and Packing a genuine 900 Watts RMS The JMaxX 114A is setting a new standard in compact affordable lightweight speakers.
FBT SUBline 118SA Processed Active Subwoofer - Black
Bass-reflex design subwoofer
460 mm (18'') high excursion woofer with 75 mm (3'') voice coil, custom made for FBT by B&C
Frequency response from 33Hz - 100Hz
1200W RMS Class D power amplifier with switch mode power supply
Digital Signal Processor with 6 presets, 4 equalization with 2 LPF Crossover Settings, 6 step digital delay line up to 3.5m
Control Panel with Stereo XLR in/outs, Volume, EQ Presets, Delay, Phase Reversal Switch 0°-180°, 3 status LED indicators
15 mm (0.59'') birch plywood scratch resistant enclosure with internal bracing
M20 (20mm) top mount speaker stand socket and two aluminum ergonomic FBT handles
Ultimax MSA-220BK Adjustable Speaker Pole With M20 Thread
The StageCore MSA220 Speaker Pole with M20 Thread is a dependable and adaptable solution for mounting your speakers in a professional audio environment.
Its rugged construction, height adjustability, and compatibility with a wide range of speakers make it an excellent choice for musicians, DJs, and audio engineers seeking reliable support for their valuable sound equipment.
With this speaker pole, you can elevate your sound and ensure a stable and secure setup at every performance.
StageCore CORE350LU3-BK Male XLR - Female XLR 3M
Female XLR Connector - Male XLR Connector, Professional Audio Cable - Includes Hook & Loop Tie
StageCore CORE350LU6-BK Male XLR - Female XLR 6M
Female XLR Connector - Male XLR Connector, Professional Audio Cable - Includes Hook & Loop Tie
FBT SL-C 118 SUBline 118 Cover - No Wheels On Sub
Cover for SUBline 118 Series
Made from hard wearing wipeable nylon, this soft lined padded cover will protect the SUBline 118 while on the road.
FBT V64 PROMaxX 114, 112 and JMaxX 114, 112 Speaker Cover
This is the perfect way to protect your FBT Pro maxx 12 or 14a speakers with this official FBT branded padded speaker cover.
FBT JMaxX 114A 900W Active Speaker
- 14" LF woofer and a 1’’ exit throat HF compression driver with 1.4” voice coil
- 2-way, bi-amplified bass reflex design cabinet
- 700W RMS LF, 200W RMS HF, Class D power amplifiers with switch mode power supply
- DSP with 4-EQ presets
- Control panel with: XLR IN and XLR LINK, Volume, EQ presets, HP filter, GND LFT switch
- 2 x M10 suspension points, 35mm (1.3/8”) top-hat speaker stand socket, wall bracket mount flange plate
- 90°H x 60°V constant directivity horn
- Stage monitor angling facility with 12°, 40° or 55° taper
- Just 14kg
FBT SUBline 118SA Processed Active Subwoofer - Black
Bass-reflex design subwoofer
460 mm (18”) high excursion woofer with 75 mm (3”) voice coil, custom made for FBT by B&C
Frequency response from 33Hz - 100Hz
1200W RMS Class D power amplifier with switch mode power supply
Digital Signal Processor with 6 presets, 4 equalization with 2 LPF Crossover Settings, 6 step digital delay line up to 3.5m
Control Panel with Stereo XLR in/outs, Volume, EQ Presets, Delay, Phase Reversal Switch 0°-180°, 3 status LED indicators
15 mm (0.59”) birch plywood scratch resistant enclosure with internal bracing
M20 (20mm) top mount speaker stand socket and two aluminum ergonomic FBT handles
Ultimax MSA-220BK Adjustable Speaker Pole With M20 Thread
High-Quality Construction:The StageCore MSA220 Speaker Pole is constructed with precision and durability in mind. It is made from robust materials that can withstand the rigours of the road and the demands of frequent use.
M20 Thread:The speaker pole features an M20 thread at the bottom, which is a widely accepted industry standard for mounting loudspeakers. This thread ensures a secure and stable connection between the pole and your speaker, minimising the risk of wobbling or accidental disconnection during performances.
Adjustable Height:This speaker pole is designed with height adjustability in mind. You can easily extend or retract the pole to achieve the desired speaker placement. Whether you need to raise your speaker to reach a larger audience or keep it at ear level for a more intimate setting, this pole provides flexibility.
Safe Load Capacity:The StageCore MSA220 Speaker Pole is engineered to support a substantial load capacity. It can securely hold heavy loudspeakers, making it suitable for a wide range of speakers used in professional audio setups.
Easy to Transport:The compact and lightweight design of this speaker pole makes it easy to transport to gigs, concerts, or events. It won't add unnecessary bulk to your equipment loadout.
Non-Slip Design:To ensure stability during use, the speaker pole features a non-slip surface. This prevents your speaker from shifting or sliding during performances, keeping your setup safe and reliable.
Compatibility:The M20 thread on the StageCore MSA220 Speaker Pole is compatible with a variety of professional loudspeakers and subwoofers, making it a versatile choice for audio professionals.
Professional Appearance:The sleek and professional design of this speaker pole complements the aesthetics of your audio setup, giving your performance area a polished and organised look.
FBT SL-C 118 SUBline 118 Cover - No Wheels On Sub
Cover for SUBline 118 Series
Made from hard wearing wipeable nylon, this soft lined padded cover will protect the SUBline 118 while on the road.
FBT JMaxX 114A 900W Active Speaker
- Code: 42632
- Configuration: 2 Way
- Built-in amplifier LF/HF: 700w/200w
- Frequency response: 45Hz - 20kHz
- Low Frequency woofer: 14" (2.5" VC)
- High Frequency driver: 1" (1.4" VC)
- Maximum SPL cont/peak: 132 dB
- Dispersion: 90 x 60
- Input connector: XLR + 6.3mm Jack
- Power cord: 5m IEC
- Net Weight: 14kg
FBT SUBline 118SA Processed Active Subwoofer - Black
Configuration: Subwoofer
Built-in amplifier LF/HF: 1200w
Built-in amplifier peak LF/HF: 2400w
Frequency response: 33Hz - 100Hz
Low Frequency woofer: 18" (3" VC)
Maximum SPL cont/peak: 134/137dB SPL
Dispersion: Omnidirectional
Input connector: Stereo XLR In/Out
Power cord: 5m PowerCon True1
Net Dimension (WxHxD): 555 x 572 x 666mm
Net Weight: 44.5kg
StageCore CORE350LU3-BK Male XLR - Female XLR 3M
- Connector A Female XLR
- Connector B Male XLR
- Length 3m
- Colour Black
StageCore CORE350LU6-BK Male XLR - Female XLR 6M
- Connector A Female XLR
- Connector B Male XLR
- Length 6m
- Colour Black
FBT SL-C 118 SUBline 118 Cover - No Wheels On Sub
Cover for SUBline 118 Series
Made from hard wearing wipeable nylon, this soft lined padded cover will protect the SUBline 118 while on the road.
